Dial Gauge Holder for Start of Delivery on Bosch PE…P Pumps (M16×1.5)

Dial Gauge Holder for Start of Delivery on Bosch PE…P Pumps (M16×1.5)

EAN: 8053670083974

Part Number (SKU): MARBED 9117 https://www.injectionpower.com/web/image/product.template/5456/image_1920?unique=89f854b
(0 review)

This tool is used for adjusting the start of delivery and for measuring the plunger clearance at TDC. OEM Bosch reference 1 688 130 021.

The Marbed 9117 is a dial gauge holder used for measuring the start of delivery (Förderbeginn) in Bosch PE…P inline pumps.
It connects to the pump inspection port with M16×1.5 thread and positions a dial gauge on the pumping element plunger.

Key benefits

  • Accurate timing adjustment for Bosch PE…P pumps

  • OEM equivalent to Bosch 1 688 130 021

  • Ensures correct engine start and combustion efficiency

  • Rugged and workshop-ready design

  • Part of Marbed’s range of start-of-delivery dial gauge holders (9117, 9174, 9513 family)

Register or Log In to Unlock Pricing and Purchase

Gain access to exclusive pricing and start shopping today!

Register Now Log In

This combination does not exist.

Contact Us
The Marbed 9117 is a dial gauge holder used for measuring the start of delivery (Förderbeginn) in Bosch PE…P inline pumps.
It connects to the pump inspection port with M16×1.5 thread and positions a dial gauge on the pumping element plunger.

FAQ

Q1. What is the Marbed 9117 used for?

To measure the start of delivery in Bosch PE…P pumps.

Q2. What is the thread size?

M16×1.5 connection.

Q3. What is the Bosch OEM reference?

Bosch 1 688 130 021.

Q4. What dial gauge does it support?

Any comparator with Ø8 mm stem, 0.01 mm division, 0–10 or 0–30 mm stroke.

Q5. How is it different from 9174 or 9513-K?

  • 9174: for Bosch PE/PS80 pumps (M24×1.5)

  • 9513-K: for Bosch MW pumps (M18×1.5)

  • 9117: for Bosch PE…P pumps (M16×1.5)
