Your Secret Weapons in Diesel Fuel Injection Repairs

Bundle of press machine and Forming Kits for the steel pipe ends, in both common-rail and conventional injection

Part Number (SKU): 9376-DK1
(0 review)

This all-inclusive set combines the power of our 20-ton hand-operated 9376-D Press with three versatile forming kits, providing you with the ultimate solution for your pipe repair needs.
Whether you're dealing with traditional or common rail injection pipes, this bundle ensures you have the right tools at your disposal.
Weight: 42kg approx
Dimensions: cm 40x30x56h

Prices are available to registerd user only. Login or Register

Using Marbed's 9376-DK1 is simple and straightforward

Let's go through the steps:

1. Selecting the Forming Kit

The bundle comes with three forming kits:

  • one for traditional injection pipes with a diameter of 6mm,
  • one for common rail injection pipes with a diameter of 6mm,
  • one for pipes with a diameter of 8mm.

Each kit includes:

  • a forming head to be inserted onto the press stem,
  • two semi-shells that act as clamps to hold the pipe during the forming operation,
  • a gauge to determine the exact measurement where to lock the pipe, leaving free the part to be deformed.

Next step


2. Positioning the Protrusion Gauge

Place the protrusion gauge on a flat surface (for example, the work table). Rest the two semi-shells on the gauge.

Next step

3. Inserting the Pipe

Position the pipe cut-off between the two semi-shells. These are held in place by the conical ring.

Next step


4. Positioning in the Press Housing

Now place the assembly (conical ring, clamp, and pipe) in the appropriate housing of the press.

Next step

5. Locking the Pipe

Use the protrusion gauge to tighten the clamp and securely lock the pipe. Once done, remove the protrusion gauge.

Next step


6. Forming the Pipe

Operate the manual pump to generate the necessary pressure to deform the end of the pipe and create the correct shape.

Next step

7. Unlocking the Pipe

To unlock the pipe, position the appropriate extraction spacer under the assembly.

Re-do from start


And there you have it! You have just used the Marbed 9376-DK1 nipple-forming tool to repair a high-pressure pipe.

With a bit of practice, you'll become faster and more accurate in this process.

Remember, if you have any questions or doubts, we're here to help.

Contact us

If you're a diesel mechanic, then you know that having the right nipple forming tool is essential.

A leaking connection can be very frustrating and expensive to fix. But now, with our nipple forming tool, you can build your own pipeline exactly how you want it!

We offer a standard 60° die for both the 6 and 8 mm diameter, as well as a special common-rail die for the 6 mm diameter.

So don't go another day without the perfect nipple forming tool - get yourself a nipple die today!

Read the article

Take your workshop to the next level with our comprehensive Marbed 9376-DK1 Bundle.

Invest in the Marbed 9376-DK1 Bundle and experience the convenience of having a comprehensive solution right at your fingertips, to achieve all this:

Repair Rather than Replace

The Marbed 9376-D Press allows you to repair high-pressure pipes or create a new one from scratch, instead of replacing with a brand new one, saving both time and money.



The press can work with both traditional injection pipes and common rail injection pipes - one tool for two jobs.


Profitable Investment

The cost of the equipment can be recouped in less than a year, thanks to the earnings from the new service offered to your customers.


Boost Your Workshop Reputation

Being able to promptly and on-site solve your customers' problems can enhance your workshop's reputation and attract new customers.


Increase Customer Loyalty

Offering a high-pressure pipe repair service can increase customer satisfaction and loyalty. This aligns with the current trend of businesses offering comprehensive services to retain their customer base.



We also provide new pipes and nuts with various thread sizes, allowing you to be self-sufficient and offer a complete service.


Future Ready

With the increasing prevalence of common rail injections, the Marbed 9376-D Press is already equipped to face future challenges. You won't have to reinvest in another more powerful tool.
