Universal Modular Cam-box
EAN: 8053670081796
Part Number (SKU): MARBED 9562-M1Base module of the Marbed Modular Testing System for diesel injection pumps without internal camshaft.
Developed to solve decades of workshop limitations — the 9562-M1 provides a single, modular base adaptable to over 20 pump types, eliminating the need for multiple dedicated camboxes.
The 9562-M1 is the core of the universal Cambox platform. Cast iron construction ensures rigidity, dimensional stability, and long-term accuracy.
It must be configured with spacers, plates, camshafts, and accessories according to the specific pump family.
Diesel workshops have long faced the challenge of testing pumps without internal camshaft (PFR, PFM, PFE, etc.), each requiring a different cambox and setup.
The Marbed 9562-M1 Universal Modular Cam-box was developed to eliminate this complexity through a modular, configurable, and universal system.
Machined from cast iron, it ensures rigidity, precision, and long-term reliability.
⚠️ The 9562-M1 itself does not include a camshaft.
It is the base module and must be completed with the appropriate spacers, plates, and camshaft depending on the pump family.
💡 Key Benefits
Universal base for more than 20 pump types.
High rigidity and dimensional accuracy thanks to cast-iron construction.
Compatible with standard diesel test benches (Deteq, Bosch, Hartridge, Maktest…).
Precision alignment of mechanical components.
Upgradeable system – every accessory available separately.
⚙️ Technical Features
| Feature | Description |
| Construction | Cast iron housing, precision machined |
| Function | Mechanical base for testing camshaft-less diesel pumps |
| Compatibility | Bosch PFR/PFM/PFE, Zexel KD/KX/MD, Denso, Yanmar, Stanadyne |
| Camshafts supported | 9564-A / 9564-B / 9564-C / 9564-E (sold separately) |
| Mounting | Via modular plates and spacers (9562-A/B/C/D/E, 9562-M4/M5) |
| Drive interface | Standard coupling (9576) |
| Finish | Ground surfaces and high-precision alignment |
| Country of manufacture | Italy |
🧰 Compatible Kits (Pre-Configured Sets)
| Kit Code | Description | Typical Applications |
| 9562-W | 1 wooden box | Workshop Base Kit (Bosch PFR..K) pumps |
| 9562-KW | 2 wooden boxes | Extended coverage (Bosch + Zexel KX + Denso + Stanadyne Kit) |
| 9562-KWY | 3 wooden boxes | Full universal configuration (Bosch + Zexel KX + Denso + Stanadyne + Yanmar kit) |
| 9562-ZX2 | 1 wooden box | Zexel Expert Kit (MD/KD/KX Zexel/Diesel Kiki pumps) |
Each configuration includes the 9562-M1 base and a selection of plates, spacers, and camshafts for the respective pump family.
Custom setups can be created by ordering components individually.
🔩 Recommended Accessories
| Component | Description |
| 9564-A/B/C/E | Camshafts with different profiles (sold separately) |
| 9562-M4 / M5 | Spacer sets for height adjustment |
| 9562-A/B/C/D/E… | Mounting plates for various pump flanges |
| 9562-F/H/L | Sliding rods for plunger control |
| 9562-G/R/I/LB | Rack connectors |
| 9478-BXS / 9680-A | Drive coupling and adapter sets |
❓ FAQ
Q1. Does the 9562-M1 include a camshaft?
No. Camshafts are ordered separately according to the pump type.
Q2. Which pumps can be tested once configured?
More than 20 types from Bosch, Zexel (Diesel Kiki), Denso, Yanmar, and Stanadyne.
Q3. What is the material of the Cambox?
High-grade cast iron, ensuring rigidity and stable geometry.
Q4. Can I expand my system later?
Yes — the 9562-M1 is modular and compatible with all Marbed components and kits.
Q5. Is it compatible with standard test benches?
Yes, it fits all common diesel test benches via the drive coupling sets.
