Product highlighting

In a huge range of products, highlighting just some of them carries a significant responsibility. Nevertheless, the subcategories listed on the left offer diverse perspectives, aiming to inspire and enhance the search process.

強調

Corso per HP0

Training service for the use of the ERT45R Simulator with the kits for the test of DENSO HP0 pumps.

Service features:
- The training course will take place in Italy at DETEQ headquarter
- Duration of 1 day ( 8 working hours )
- Maximum for 2 participants
- Is held in English Language
- The standard training is destined to participants already operators of diesel systems.
- Is excluded the technical instruction on the technology of the components which are object of the machine operativity. This kind of service can be provided only upon agreement with DETEQ.
-At the end of the training will be issued a frequency profit Certificate

The course includes the training provided by DETEQ Technicians, for:
- Performance features of the products
- Details and installation problems
- Methods of use
- Maintenance
- Practice with the help of DETEQ technicians. The participants will be first instructed and then followed step by step by our technical personnel for practical exercises.

Corso di formazione per l'utilizzo del simulatore ERT45R e del kit per la prova delle pompe Delphi DPCN.

Training service for the use of the ERT45R Simulator with the kits for the test of DELPHI DPCN pumps. This is not a full training concerning the complete overhault of this pump.
The matters of this training are the following:
- Performance features of the products
- Details and installation problems
- Methods of use
- Maintenance
- Practice with the help of DETEQ technicians. The participants will be first instructed and then followed step by step by our technical personnel for practical exercises.
- Location: in Italy at DETEQ headquarter
- Duration: 1 day (8 working hours)
- Maximum number of attenders: 2 diesel specialists having skills on this type of pump
- Is held in English Language
- Individual Certificate of Training is delivered.

DIT31 - Test bench for diesel injectors.

The test bench DIT31 is a modular solution to test the common rail injectors (the additional TC38 triggering unit is required) as well as the conventional and 2 stage (double spring) diesel injectors.
The applied technology allows the test parameters to be determined reliably on each injection, with greater precision and resolution than using on average long test cycles to collect a measurable quantity of fuel.

Main features:
- Main tank 3 lt. with 15 micron filter
- Separated container for the collection of the contaminated liquid
- Large atomization chamber with smoke extraction and halogen lamp
- Pneumatic operated pump unit, the standard version is suitable up to 1400 BAR (compressed air 8-10 BAR is required). Special versions can be installed as optional to generate more pressure and flow.
- Pneumatic vice for the automatic clamping of the injector
- Digital manometer with the reading scale selection (BAR/PSI)
- Printer to generate the test report
- Program for conventional injectors: (1) measurement of the NOP (nozzle opening pressure) and calculation of the back-leakage time.
- Program for Double-spring injectors: (2) measurement of the NOP1 (1st stage) and NOP2 (2nd stage), calculation of the back-leakage time and determination of the K factor.
- 2 programs for common rail injectors: (3) identification of the return flow (leakage time), (4) of the opening delay, the injection time and the injected fuel quantity (dp).
- 24 months warranty. User's and servicing manual in English language.
