Kit de programación para el simulador ERT45R: Prueba de bombas diésel rotativas Bosch VE-EDC de 1ª generación (regulador resistivo).

EAN: IP006599

Part Number (SKU): 81.01.1011

El kit incluye:
- tarjeta inteligente de programación que permite al simulador ERT45R activar las funciones necesarias para probar este tipo de bomba
- cable básico (2 mt. de longitud)
- cable adaptador 81.02.434 (similar al 0986612434 de Bosch). Cables adicionales disponibles bajo pedido
- Manual ilustrado de instrucciones paso a paso.
- Datos de prueba para calibrar las bombas que se pueden conectar al cable adaptador 81.02.434

Regístrate o Inicia Sesión para Desbloquear Precios y Comprar

Accede a precios exclusivos y comienza a comprar hoy mismo.

Regístrate Ahora Iniciar Sesión

Esta combinación no existe.

ERT45R APPLICATION KIT · 81.01.1011

Bosch VE-EDC 1st Gen · Resistive Regulator

Add Bosch VE-EDC first-generation testing capability to the same ERT45R control platform.

This programming kit provides the application software, cabling, documentation and reference test data required for the Bosch VE-EDC family covered by the supplied adapter cable.

ERT45R control unit used with the Bosch VE-EDC programming kit

What is included

The kit combines the software authorization with the physical connection and operating documentation required for this application.

Programming smartcard

Enables the ERT45R functions and operating logic required to test this Bosch VE-EDC pump family.

2 m basic cable

Provides the common connection between the ERT45R control unit and the application-specific pump adapter cable.

DETEQ 81.02.434 adapter cable for Bosch VE-EDC pumps

Adapter cable 81.02.434

Supplied as the standard pump adapter with this kit. It is similar to Bosch reference 0 986 612 434.

The documented applications include connectors commonly used on IVECO, FIAT, ALFA and LANCIA pumps. Additional adapter cables are available separately for other VE-EDC configurations.

Illustrated ERT45R Bosch VE-EDC operating manual

Illustrated step-by-step manual

Documents setup and operation of the application so that the technician can follow the required test procedure on the ERT45R platform.

ERT45R registration and license form for application test data

Registration and reference test data

The kit includes access to the available test data for pumps that can be connected through adapter cable 81.02.434. The original page documents registration and acceptance of the license agreement as the route for receiving this reference data.

This kit does not replace the ERT45R control unit

81.01.1011 is an application kit. It requires the ERT45R control unit 81.01.080B to create a functional test setup.

Common core

81.01.080B ERT45R

Provides the programmable control hardware and common operator interface.

Application layer

81.01.1011 Smartcard

Loads the Bosch VE-EDC resistive-regulator control strategy and operating procedure.

Pump interface

81.02.434 + optional cables

Connects the ERT45R platform to the specific pump connector used on the application being tested.

Explore the ERT45R system concept

BOSCH VE ELECTRONIC PUMPS

Same test function. Two different regulator technologies.

Bosch electronically controlled VE pumps use two regulator technologies that require different ERT45R programming kits.

81.01.1011 · VE-EDC

Resistive regulator

Use this kit for first-generation Bosch VE-EDC pumps using the resistive regulator technology.

81.01.1012 · VE-HDK

Inductive regulator

Use this kit for second-generation Bosch VE-HDK pumps using the inductive regulator technology.

The two technologies are electrically different. The 1011 and 1012 perform the same role inside the ERT45R system, but they are not interchangeable and should not be combined as if one were an extension of the other. Select the programming kit according to the regulator fitted to the pump.

Not sure which regulator is fitted? Our technical article shows how to distinguish the two Bosch VE electronic regulator generations.

How to identify EDC and HDK regulators

Extend the VE-EDC test setup when required

The current product page already connects this kit with useful ERT45R accessories and additional VE-EDC adapter cables.

Electronic advance-piston travel measurement

The optional 81.01.1001 sensor allows advance-piston displacement to be read electronically on the ERT45R display, using the appropriate pump adapter.

OTA electrical diagnostics

The optional 81.21.090 OTA interface simplifies continuity, resistance and short-circuit checks on pump sensors and actuators before connection to ERT45R.

Fuel-temperature monitoring

VTR110 can be added to monitor fuel temperature at the pump outlet and support faster temperature management during testing.

Bosch VE-EDC application chart for the ERT45R system

Shared Bosch VE adapter-cable family

The 81.01.1011 and 81.01.1012 kits belong to the same Bosch VE electronic-pump ecosystem and share the wider family of application-specific adapter cables. The cable required depends on the connector and pump configuration; 81.01.1011 is supplied with 81.02.434 as its standard adapter.

The product relationships already associated with 81.01.1011 include application cables for Audi, Volkswagen, BMW, Opel, Ford, PSA/Mercedes, Rover, Chrysler, Nissan and other documented VE-EDC configurations.

The application investment remains part of the ERT45R ecosystem

The programming smartcard is authorized for the ERT45R unit or units associated with the workshop. If the card is damaged or lost, the complete programming kit does not need to be purchased again when the original kit purchase can be documented and the corresponding ERT45R serial number is known.

For workshops operating two ERT45R control units, the application can be authorized for both units, increasing operational flexibility without duplicating the programming-kit investment.

Professional training for use of the ERT45R Bosch VE application kits

Training is available separately

Hands-on ERT45R training for Bosch VE applications is available as a separate service. It focuses on product operation, installation, methods of use, maintenance and practical exercises with DETEQ technicians.

View the training service
