Hand pump for calibrating and checking the operations of
the diesel injectors
- precise adjustment of the injection pressure (adjust the
opening pressure of the injection nozzle)
- control of the spray atomization (pattern and vibration
characteristics)
- control tightness (leaks)
- equipped with bypass valve for the manometer.
Dial: 0 - 600 bars gliceroil
Tank fitted with a filter
Supplied with 2 connection pipes: 14-14 and 14-12 mm

Reamer with helical conical millers and diam 20mm shimming aluminium washers for nozzle holder copper cases.
Kit composed by:
1 x 9640 helical conical spare miller diam.22 IVECO
1 x 9640-A Conical spare miller diam.20,5 IVECO 115/17
1 x 9524 plane spare miller diam.22 IVECO 50NC-90NC
1 x 9524-A plane spare miller diam.21 VOLVO MAN

The rubber coating strengthens the tube which therefore vibrates less and produces less noise, extending its life. Specifications:
- external diameter: 6 mm
- internal diameter: 2 mm
- thickness: 2 mm
- length: 450 mm
- nuts: M12x1,5 mm - M14x1,5 mm
Similar to Bosch reference 1 680 750 073, Hartridge AHP120

Allen wrench, 10 mm hexagon drive to dismount the high-pressure sealing ring of common-rail injectors - 6,5 mm hole

It creates 12 compartments of various sizes to house the components of the rotary pumps during assembly and disassembly operations.
Thanks to the perforated bottom, the fuel residues inside the pump are collected in the lower tray which can be easily released.

Overall dimensions: approx. 30x40x15 cm

The Marbed 9853-L Vacuum and Pressure Hand Pump is an exceptional tool designed to meet the needs of professionals across diverse applications. Its versatility makes it suitable for a broad range of automotive and industrial tasks, with a particular emphasis on supporting diesel fuel injection specialists on:
- diesel pressure up to + 1.5 bar on turbocharger, LDA flow control valve, turbines, etc.
- vacuum -1000 mbar on petrol turbocharger, valve filters, membrane for diesel pump regulator, etc.

Similar to Bosch reference 0 986 611 275, KDEP 2921

Extended configuration of special holders, probes and comparator (in wooden case) for the phasing of the Bosch VE rotary pumps.

Similar to the reference Bosch 0 986 611 120, Bosch 1 682 027 002, KDEP 2896.

Marbed 9562-KW Cambox Konfigürasyonu ile Hassasiyet ve Çok Yönlülüğün Kilidini Açın Dizel enjeksiyon uzmanları için tasarlanan bu sistem, mevcut herhangi bir test tezgahının yeteneklerini genişleterek aşağıdakiler de dahil olmak üzere sektör lideri modellerle uyumlu hale getirir: - Bosch PFR1K, 2K, 3K, 4K - Zexel PFR2KX, PFR3KX, PFR4KX - Stanadyne PFR (aynı anda iki pompayı test edin) - Bosch Q boyutu - Nippondenso mini (1 ila 4 silindir) Kompakt motor bileşenlerini veya hassas zamanlama kalibrasyonu gerektiren daha büyük kurulumları test ediyor olun, 9562-KW eşsiz performans ve esneklik sunar.

It applies on any test bench for diesel fuel injection pumps.
Combining the Cambox with additional plates and spacers, a complete system is obtained for testing up to 19 types of immersed pumps manufactured by Bosch, Denso and Zexel.
This configuration is supplied in three wooden boxes and includes the following components:

- universal cambox (9562-M1) and spacers (9562-M4, 9562-M5)
- 4 cyls Camshaft 7 mm (9564-A) and 6 mm (9564-B)
- 1 cyl Camshaft (9564-C)
- plate for Bosch PFR..1K pumps (9562-A)
- plate for Bosch PFR..1K pumps (9562-B)
- plate for Bosch PFR..2K pumps (9562-C)
- plate for Bosch PFR..3K pumps (9562-D)
- plate for Bosch PFR..4K pumps (9562-E)
- plate for Q-size pumps (9563)
- plate for Stanadyne pumps (9562-M3)
- plate for Zexel PFR..2K pumps (9891)
- plate for Zexel PFR..3K pumps (9892)
- plate for Zexel PFR..4K pumps (9893)
- plate for Nippondenso mini pump 1 cyl. (9562-N)
- plate for Nippondenso mini pump 2-3-4 cyl. (9562-M2)
- rod (9562-F, 9562-L, 9562-H) and controller (9562-F, 9562-L, 9562-H) and fuel controller connectors (9562-G, 9562-LB, 9562-I, 9562-R)
- plate for Yanmar 3 cil pumps (TD9001)
- plate for Yanmar 3 cil pumps (TD9003)
- plate for Yanmar 2 cil pumps (TD9004)
- plate for Bosch PFM..1P pumps (9562-P)
- Cambox mounting flange (9478-BXS)
- drive coupling (9576)

Flange for CAV-DPS diam.68 mm.(Ford Transit) BMW VE electronic (BH 1685720219)

Box complete with universal comparator support to take dimension of rod stroke on pumps on line BOSCH P,P7100,8500,A,B,BV,BOSCH MW,M,RSF ando so on

Universal comparator supports box for delivery start on test bench and check for BOSCH P injection pumps setting on the engine

Set of 9 pentagonal reamers to remove dirt and oxide from diesel nozzle holes.
3 pieces by 3 different dimensions: 0.05 // 0.07 // 0.10 mm
