Bracket for assembly / disassembly of common rail pumps, on the workbench.

The circular support must be installed on revolving bases (ref. 8132 or 9260).
The system consists of a circular ring support, on which the (removable) bracket with adjustable projection is mounted, which allows to press the tappets. The circular holder holds an interchangeable round flange, which can rotate 360 degrees and can be locked in any position.
The internal flange allows to fix CP1, CP3, CP4, HP1, HP3, HP4, Delphi and VDO pumps.
Similar to 0 986 612 794

As an additional option, the following optional flanges are also available:
- 8131, for CP3.4 pumps
- 9402, for mechanical pumps A, M, VE, DPC

Torx bit
Similar to 0 986 613 145

10 mm Oldham coupling to drive diesel pumps on any test bench.

Warrants the centered clamping of the pumps having 50 mm hub diameter, on any test bench. The flange requires 9680-A universal cradle or similar.

Flexible High pressure line L=600 mm. - M12x1,5 - M12x1,5

This device allows to monitor the pump body pressure (5 BAR).
It is also equipped with ball valve, to measure the negative pressure generated by the pump.
Caution: Not all test benches are able to supply the amount of flow required by the comon rail pumps. Therefore, it is crucial to monitor that, during the test, the pump does not go into cavitation.

Experience the reliability of the Marbed 9578-B, a robust steel coupling half designed to drive diesel pumps on test benches. Compatible with PE..A, PE..B, P7, PE..MW..S1000, and Bosch reference part 1 686 430 024, it features a 27 mm hex nut for quick removal and versatile application.

يضمن شفة Marbed 8155-E التثبيت المركزي لمعظم مضخات السكك الحديدية المشتركة (Bosch CP1، CP3، CP4، Delphi، Denso، VDO) على أي منصة اختبار. مُجهزة بأربع حلقات تخفيض (Ø 50، 60، 68، 80 مم) ومتوافقة مع مضخات CP1K. يتطلب حامل Marbed 9680-A العالمي أو دعامة مماثلة للتركيب الصحيح.

Swivel vice for Common-rail pumps
